Smaller physical size 295W solar panel, great for fitting into tigher spaces on Vans, Campers, Motorhomes and Boats.   Measuring just 1504 X 1002 X 35mm, they offer great flexiblity for smaller and more complex shaped roofs.  The Perlight 295W Delta Mono Triple Black 54 Cell module is a classic all black mono-crystalline solar panel which use the state-of-the-art technology in the design & manufacturing process, thus ensure the superior quality as well as the modern appearance. The Perlight 295W Delta Mono Triple Black 54 Cell module is designed especially for the European market by Perlight, recognizing the importance of aesthetics in construction. When installed in arrays, the Delta Black offers a more uniform appearance, enabling PV modules to integrate into new and existing buildings without necessarily making the array the focal point of the building. 54 cell Monocrystalline module 295 W output capacity Compatible with all mainstream mounting systems and roof types Black frames Static load passed protection bar 12-year warranty 12-year 90% Power-Max Performance Guarantee 25-year 80% Power-Max Performance Guarantee Underwritten by Chubb Insurance Reliability High  efficiency  crystalline  solar  cell  (module efficiency 17%),  producing  maximum  power  even   under  low  light  conditions. Highly  transparent,  low-­iron,  tempered  glass  and  antireflective  coating  increases  energy yield. Use  of  Ethylene  Vinyl  Acetate  (EVA)  in production  guarantees  longevity  of  the  panels. Anodized  aluminium  frame  improves  load resistance  capabilities  for  heavy  wind  loads Integrated  bypass  diodes  to  protect  the  solar cell  circuit  from  hot  spots  during  partial  shadowing. Safety High reliability bypass diodes Lock mechanism equipped connectors Modules  are  IEC61730  safety  rated  for  high  wind  pressure,   hail  impact,  snow  load  and  fire Eco-Friendly Manufactured in ISO14000 certified manufacturing plant

If you wish to see the large image version of the fault, please email info@bimblesolar.com and reference the panel code, we will email you a full size image.   Datasheets or further information Bimble 100w Product listing Ningbo 170w - Data label on 'Downloads tab' - Dimensions: 1580 x 808 x 46mm, VOC 44.0V Sun 180w - Data label on 'Downloads tab' - Dimensions: 950mm x 1570mm, VOC 32.6V Yingli 220w (NOTE - Has QC connectors, NOT MC4) Datasheet Bisol 250w Datasheet SolarWorld 250w - Datasheet on 'Downloads' tab... note panels are mono not poly Solvis 260w Datasheet JA 265w Datasheet Perlight 270w Datasheet Canadian Solar 300w Datasheet JA 310w Datasheet JA 330w Datasheet LG 355w Datasheet JA 370w Datasheet JA 380w Datasheet LG Bi-Facial 400w - Datasheet LG Bi-Facial 405w - Datasheet LG Bi-Facial 415w - Datasheet on 'Downloads' tab JA 495w Datasheet Canadian Solar 540w Datasheet

330W Perlight Solar Panels Mono Percium - All Black, 1665 x1002 x 35mm The Black Plus Series is an excellent all-round module, which is sleek and robust. Proven performance, stylish appearance and high-efficiency monocrystalline PERC cells. Concealed link busbars at either end of the module provide a more elegant finish than other black modules on the market. Crafted with precision and expert skill, the Black Plus Series offers outstanding build quality and reliability. High efficiency PERC technology 5 busbar Excellent low-light performance Clampable on Long & Short sides Extremely reliable screw-less frame Compatible with in-roof systems MCS Certified Worldwide accreditation Use with Tracer MPPT's - for a single panel on a 12V system you can use a 30A MPPT with this panel.  This listing is for 1 panel, simply select how many you need in the quantity.  There is NO MINIMIUM Order.

Q Cells 380W Mono Q Peak Duo BLK ML-G9 All Black MC4 Panels - Monocrystallines Rating: 380W Efficiency: 19.8% Width: 1,030mm Height: 1,840mm Patent protected Q.Antum passivated emitter rear contact (PERC) technology, 132 (half) cell format with zero gap cell layout, boosts module efficiency up to 20.6% Optimal yields, whatever the weather with excellent low-light and temperature behaviour. Long-term yield security with Anti LID Technology, Anti PID Technology1, Hot-Spot Protect and Traceable Quality Tra.Q™. Extreme weather rating. High-tech aluminium alloy frame, certified for high snow (6000Pa) and wind loads (4000Pa). Includes 12-year product warranty and 25-year linear performance warranty Q.ANTUM DUO combines cutting edge cell separation and innovative wiring with Q.ANTUM technology Please Note: Q Cells does not recommend their modules to be fitted on In-Roof mounting systems like GSE

LG BiFacial Solar Panel 440W, Dimensions: 2130 x 1042 x 40mm These panels have a glass back sheet so they absorb sun which bounces back from behind the panel.  Great for low light and cloudy conditions. These are ideally suited to boats with a white roof as you can see gains of upto 26% from the reflection of light back from the white surface making the panel 554W.  Any surface will work, but white gives you the best refraction of light back to the panel, or you can add aluminium solar reflective paint on the roof under the panel to get the best gain. If using this panel with MPPT you should calculate this panel as 540W so that you do no overload the MPPT.  Tracer MPPT's have current limiting so it doesn't matter if you go over the rated amps, but Outback will be damaged by too much power. The LG NeON® 2 BiFacial is designed to absorb irradiance not only from the front but also the rear of its NeON® cell by using a trans­parent back sheet. The dual face of the cell allows for higher energy generation. Thanks to a combination of highly efficient bifacial n-type NeON® cells with Cello technology, which replaces traditional 4 or 5 busbars with 12 thin wires, LG NeON® 2 BiFacial modules can achieve up to 30% more energy than standard PV module. Features Enhanced Performance Warranty LG NeON® 2 BiFacial has an enhanced performance warranty. LG NeON® 2 BiFacial is guaranteed at least 86% of initial performance after 25 years. Bifacial Energy Yield LG NeON® 2 BiFacial modules use highly efficient bifacial solar cell with Cello technology..Through the Cello technology, LG NeON® 2 BiFacial can achieve up to 30% more energy than monofacial modules (under optimal conditions) Better Performance on a Sunny Day LG NeON® 2 BiFacial now performs better on sunny days thanks to its improved temperature coefficient. More Generation on a Cloudy Day LG NeON® 2 BiFacial gives good performance even on a cloudy day due to its low energy reduction in weak sunlight. BOS (Balance Of System) Saving LG NeON® 2 BiFacial can reduce the total num­ber of strings due to its high module efficiency resulting in a more cost effective and efficient solar power system. Near Zero LID (Light Induced Degradation) The n-type cells used in LG NeON® 2 BiFacial have almost no boron, which may cause the initial efficiency to drop, leading to less LID.   This listing is for 1 panel, simply select how many you need in the quantity.  There is NO MINIMIUM Order.

655W Our Largest Ever Wattage in a single panel!  Dimensions 2384 x 1303 x 35 mm CSI Solar Co., Ltd. is committed to providing high quality solar products, solar system solutions and services to customers around the world. Canadian Solar was recognized as the No. 1 module supplier for quality and performance/price ratio in the IHS Module Customer Insight Survey, and is a leading PV project developer and manufacturer of solar modules, with over 50 GW deployed around the world since 2001. MORE POWER Module efficiency up to 21.5 % Up to 4.5 % lower LCOE Up to 5.6 % lower system cost Comprehensive LID / LeTID mitigation technology, up to 50% lower degradation Compatible with mainstream trackers, cost effective product for utility power plant Better shading tolerance Minimizes micro-crack impacts Heavy snow load up to 5400 Pa, wind load up to 2400 Pa*

NOTE - This product has cheaper delivery to business addresses. 6v Trojan Battery T105, 225Ah Manufactured by Trojan, the market leader in quality Deep Cycle manufacturing. Consumer and trade recognised brand. Renowned quality. Brand Trojan Voltage 6 Volts Technology Wet Capacity (C5) 185 Ah Capacity (C10) 207 Ah Capacity (C20) 225 Ah Capacity (C100) 250 Ah Length 262 mm Width 181 mm Height inc. terms 281 mm Guarantee 1 Year

Eight x 6v Trojan Battery T105, 225Ah Manufactured by Trojan, the market leader in quality Deep Cycle manufacturing. Consumer and trade recognised brand. Renowned quality. 6 Volt  (220Ah @ 20hr rate - 180Ah @ 5hr rate). 26kg - 264mm length x 181mm wide x 276mm high. Terminals available as M8 stud LPT. Brand Trojan Voltage 6 Volts Technology Wet Capacity (C5) 185 Ah Capacity (C10) 207 Ah Capacity (C20) 225 Ah Capacity (C100) 250 Ah Length 262 mm Width 181 mm Height inc. terms 281 mm This product has cheaper delivery to business addresses.

For 12V Solar System: 750W solar panel (150V for max input voltage 138V@ 25C) For 24V Solar System: 1500W solar panel (150V for max input voltage 138V@ 25C) For 48V Solar System: 3000W solar panel (150V for max input voltage 138V@ 25C) No Fan for silent operation, great for vans, boats or any live in spaces ​The AN tracer models have a current limiting function, you can connect 1.5 times the rated power to the controller ​so if your on a budget you can use a smaller controller with more panels so that you get more power in winter or low light but don't risk overloading the controller in the summer.  The output will be limited to the max listed above. Supports upto 6 units in parallel with a PTA adapter for communication and equalize of the paralleled units Local temperature sensor included, remote 3m temperture sensor optional. Tracer AN series controller, based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithm, with dual-core processor architecture and common negative design, has the features of high response speed, high reliability, and high industrial standard. MSRT can guarantee very high conversion efficiency in any charge power, which sharply improves the energy efficiency of solar system; Advanced MPPT control algorithm minimize the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as high conversion efficiency under high or low power, so that in any situation, Tracer AN products can rapidly track the maximum power point (MPP) of PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current and automatic power reduction function fully ensure the stability when works with oversize PV modules and operate under high temperature environment. With the adaptive three-stage charging mode based on digital control circuit, Tracer AN series controllers can effectively prolong the life-cycle of battery and significantly improve the system performance. The load, utility or generator auto-control relays make it easy to compose the hybrid power system. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection, effectively ensure the safer and more reliable operation of the solar system for a longer service time. The isolated RS485 interface with standard MODBUS communication protocol and 5V power supply makes it easy for customer to expand the application, Support up to 8 charging in parallel to expand system and meet with different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household system and field monitoring, etc. Features CE certification(LVD EN/IEC62109,EMC EN61000-6-1/3) High quality & low failure rate components of ST and Infineon to ensure the product’s life Advanced MPPT technology & ultra-fast tracking speed is up to 99.5% guaranteed Maximum DC/DC transfer efficiency is as high as 98.7% Advanced MPPT control algorithm will minimize the MPP loss rate and loss time The accuracy of the recognition and tracking at the highest point of multiple-peaks MPP The wider range of MPP operating voltage. Auto control system to limit the charging power & current go over the rated value. Support 4 charging options: Sealed, Gel, Flooded and User. Battery temperature compensation function Real-time energy recording and statistical function Automatic over-temperature power reduction function Hundred percent full load operation in working environment temperature range within charging & discharging Support up to 6 units in parallel to expand system Load relay control external load switch signal to realize diversified load work modes The first and the second disconnection of load control, contain two relay’s contact. Auto-control of utility and generator relay design Utility or generator auto-control relays make it easy to compose the hybrid power system The remote temperature and the voltage sensor design will collect accurate data of battery temperature and voltage Isolated RS-485 with 5VDC/200mA to protect output for no power devices with MODBUS protocol To monitor or set the parameters by using the phone Apps or PC software. Protection: PV Over Current/power • Night Reverse Charging • Battery Overheating PV Short Circuit Battery Over Voltage Controller Overheating PV Reverse Polarity Battery Over Discharge TVS High Voltage Transients Item  Tracer6415AN  Tracer10415AN  Nominal System Voltage  12/24/36/48VDCVDC or Auto  Battery Input Voltage Range  8V~68V  Battery Type  Sealed/Gel/Flooded/User  Battery fuse  80A/58V  Rated charge current  60A  100A  Rated charge Power  750W/12V 1500W/24V 2250W/36V 3000W/48V  1250W/12V 2500W/24V 3750W/36V 5000W/48V  Max. PV open circuit voltage  150V¹ 138V²  MPP Voltage Range  (Battery Voltage +2V) ~108V³  Tracking efficiency  ≥99.5%  Conversion efficiency  ≤98.7%  Temperature compensate coefficient  -3mV/°C/2V(Default)  Self-consumption  98mA/12V;60mA/24V;50mA/36V;46mA/48V  Grounding  Common negative  Relay  Rated Value:5A/30VDC; Max. Value:0.5A/60VDC  RS485 interface  RS485(RJ45)  LCD backlight time  60S(Default)   1At minimum operating environment temperature; 2At 25°C environment temperature 3The maximum PV open circuit voltage must never exceed 138V or 180V at 25°C environment temperature. Item  Tracer6210/6415/6420AN  Tracer10415/10420AN  Dimension  340×236×119mm  394×242×143mm  Mounting dimension  260×224mm  300×230mm  Mounting hole size  Φ7  Terminal  2AWG(35mm2)  2AWG(35mm2)  Recommended cable  16mm2(5AWG)  35mm2(2AWG)  Weight  4.5kg  7.4kg  Download Manual

For 12V Solar System: 1250W solar panel (150V for max input voltage 138V@ 25C) For 24V Solar System: 2500W solar panel (150V for max input voltage 138V@ 25C) For 48V Solar System: 5000W solar panel (150V for max input voltage 138V@ 25C) No Fan for silent operation, great for vans, boats or any live in spaces ​The AN tracer models have a current limiting function, you can connect up to 1.5 times the rated power to the controller ​so if your on a budget you can use a smaller controller with more panels so that you get more power in winter or low light but don't risk overloading the controller in the summer.  The output will be limited to the max listed above. Supports up to 6 units in parallel with a PTA adapter for communication and equalize of the paralleled units Tracer AN series controller, based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithm, with dual-core processor architecture and common negative design, has the features of high response speed, high reliability, and high industrial standard. MSRT can guarantee very high conversion efficiency in any charge power, which sharply improves the energy efficiency of solar system; Advanced MPPT control algorithm minimize the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as high conversion efficiency under high or low power, so that in any situation, Tracer AN products can rapidly track the maximum power point (MPP) of PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current and automatic power reduction function fully ensure the stability when works with oversize PV modules and operate under high temperature environment. With the adaptive three-stage charging mode based on digital control circuit, Tracer AN series controllers can effectively prolong the life-cycle of battery and significantly improve the system performance. The load, utility or generator auto-control relays make it easy to compose the hybrid power system. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection, effectively ensure the safer and more reliable operation of the solar system for a longer service time. The isolated RS485 interface with standard MODBUS communication protocol and 5V power supply makes it easy for customer to expand the application, Support up to 8 charging in parallel to expand system and meet with different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household system and field monitoring, etc. Features CE certification(LVD EN/IEC62109,EMC EN61000-6-1/3) High quality & low failure rate components of ST and Infineon to ensure the product’s life Advanced MPPT technology & ultra-fast tracking speed is up to 99.5% guaranteed Maximum DC/DC transfer efficiency is as high as 98.7% Advanced MPPT control algorithm will minimize the MPP loss rate and loss time The accuracy of the recognition and tracking at the highest point of multiple-peaks MPP The wider range of MPP operating voltage. Auto control system to limit the charging power & current go over the rated value. Support 4 charging options: Sealed, Gel, Flooded and User. Battery temperature compensation function Real-time energy recording and statistical function Automatic over-temperature power reduction function Hundred percent full load operation in working environment temperature range within charging & discharging Support up to 6 units in parallel to expand system Load relay control external load switch signal to realize diversified load work modes The first and the second disconnection of load control, contain two relay’s contact. Auto-control of utility and generator relay design Utility or generator auto-control relays make it easy to compose the hybrid power system The remote temperature and the voltage sensor design will collect accurate data of battery temperature and voltage Isolated RS-485 with 5VDC/200mA to protect output for no power devices with MODBUS protocol To monitor or set the parameters by using the phone Apps or PC software. Protection: PV Over Current/power • Night Reverse Charging • Battery Overheating PV Short Circuit Battery Over Voltage Controller Overheating PV Reverse Polarity Battery Over Discharge TVS High Voltage Transients Item  Tracer6415AN  Tracer10415AN  Nominal System Voltage  12/24/36/48VDCVDC or Auto  Battery Input Voltage Range  8V~68V  Battery Type  Sealed/Gel/Flooded/User  Battery fuse  80A/58V  Rated charge current  60A  100A  Rated charge Power  750W/12V 1500W/24V 2250W/36V 3000W/48V  1250W/12V 2500W/24V 3750W/36V 5000W/48V  Max. PV open circuit voltage  150V¹ 138V²  MPP Voltage Range  (Battery Voltage +2V) ~108V³  Tracking efficiency  ≥99.5%  Conversion efficiency  ≤98.7%  Temperature compensate coefficient  -3mV/°C/2V(Default)  Self-consumption  98mA/12V;60mA/24V;50mA/36V;46mA/48V  Grounding  Common negative  Relay  Rated Value:5A/30VDC; Max. Value:0.5A/60VDC  RS485 interface  RS485(RJ45)  LCD backlight time  60S(Default)  1At minimum operating environment temperature; 2At 25°C environment temperature 3The maximum PV open circuit voltage must never exceed 138V or 180V at 25°C environment temperature. Item  Tracer6210/6415/6420AN  Tracer10415/10420AN  Dimension  340×236×119mm  394×242×143mm  Mounting dimension  260×224mm  300×230mm  Mounting hole size  Φ7  Terminal  2AWG(35mm2)  2AWG(35mm2)  Recommended cable  16mm2(5AWG)  35mm2(2AWG)  Weight  4.5kg  7.4kg  Download Manual

THE NEW VFXR-SERIES 7 Features In One Device GENERATOR MODE - CONNECT THE VFXR TO ANY GENERATOR: 1. Cover current consumption 2. Charge batteries SUPPORT MODE- CONNECT THE VFXR TO ANY INVERTER TO EXPAND THE OUTPUT POWER: 1. Cover consumption with your inverter (any brand) 2. Cover your additional consumption with the VFXR (in cooperation with any brand) GRID TIED MODE - INJECT EXCESSIVE POWER TO THE GRID: 3. Charge your batteries 4. Sell not consumed power to the grid UPS MODE - USE THE BATTERIES IF THE GRID FAILS: 5. Cover consumption with the grid 6. In case of grid failure, switch to batteries without interruption GRIDZERO MODE - USE THE GRID IF SOLAR POWER IS NOT AVAILABLE AND COVER HIGHER LOADS WITH SMALL INVERTERS: 7. Cover consumption with solar power (even with small inverters) 8. Take additional power from the grid to double the output of your inverter MINI GRID MODE - USE THE GRID WHEN BATTERIES ARE LOW: 9. Cover consumption with solar power 10. Connect to the grid when batteries are low BACKUP MODE - COVER GRID FAILURES WITH YOUR SOLAR SYSTEM: 11. Cover consumption with the grid 12. In grid failure, switch to solar system The latest, most advanced features on the industry’s most trusted and proven platform—that’s the essence of OutBack’s new FXR Series of Grid/Hybrid inverter/chargers. Capable of off-grid or grid-connected operation in a single model, the FXR Grid/Hybrid inverter/chargers provide system designers with unprecedented flexibility and compatibility for nearly any power conversion scenario. The new FXR features and technologies on the acclaimed FX platform include: Both off-grid and grid-tied functionality in one unit Seven programmable modes, including GridZero and Support Mode, and built-in networked communications Advanced Battery Charging (ABC) with expanded charging voltages and time parameters, enabling system designers to accommodate the specific charging profiles and algorithms of new and emerging energy storage technologies including Lithium Ion, Aqueous Ion and Flow Chemistry batteries Easy system upgradability in the field FXR inverter/chargers can be paired with a MATE3 to add OPTICS RE to monitor and control system performance from any location. Available in power ranges from 2000W-3000W, multiple units may be stacked and connected with other OutBack Power electronics for more seamless system integration and the ability to function in a wide variety of applications, and system sizes. Up to nine inverters can be combined in a 3-phase system with the 12V, 24V or 48V models, and up to 30kW in a grid-tied 24V or 48V system. The exclusive modular system architecture means that increased power output is just an additional FXR inverter/charger away. Available in sealed or vented units with NEMA type 1 die-cast aluminum chassis designed to operate in the harshest environmental conditions such as high temperatures, humidity or corrosive salt air, the FXR’s continue in OutBack’s tradition of absolute dependability in mission critical installations no matter how harsh or challenging the conditions. Please Note: The new VFXR range only work with a Mate 3 (the standard Mate or Mate B will not work with them) Info and Specs on Outback site

400W DC Solar Water Pump and MPPT Controller Includes DC Solar Pump Controller and Submersible Water Pump. Solar Panels required: 600W Motor Power: 400W

Ideal for glamping tents or structures that need simple lighting and USB sockets. Use the LOAD OUT of the controller to keep the battery happy by running lights and USBs from the controller, which you can set to switch off at 12.0v and keep your batteries happy and your guests from killing your battery! Use some of the 6mm solar cable to wire from the controller to the USB socket.

Victron pure sinewave output, high peak power and high efficiency in a compact unit. Models range from 250VA to 1200VA with UK socket - other socket outlets available on request These inverters allow you to power domestic equipment - requiring 230VAC - using 'leisure' or 'automotive' batteries rated at 12V Bulit in DC fuse in all models but not replaceable in all models - see the manual for further details on which models carry the replaceable fuse. Consider adding a battery isolator switch https://www.bimblesolar.com/300a-blue-sea-battery-isolator VE.Direct communication port The VE.Direct port can be connected to: • A computer (VE.Direct to USB interface cable needed) • Apple and Android smartphones, tablets, MacBook’s and other devices (VE.Direct Bluetooth Smart dongle needed) Fully configurable: • Low battery voltage alarm trip and reset levels • Low battery voltage cut-off and restart levels • Dynamic cut-off: load dependent cut-off level • Output voltage 210 - 245V • Frequency 50 Hz or 60 Hz • ECO mode on/off and ECO mode sense level Monitoring: • In- and output voltage, % load and alarms Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature. High start-up power Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools. ECO mode When in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on. Remote on/off A remote on/off switch can be connected to a two pole connector, or between battery plus and the left hand contact of the two pole connector Spec Sheet See the Download tab on this listing

See Datasheet tab

See Datasheet tab

See Datasheet tab

See Datasheet tab

See Datasheet tab

See Datasheet tab

See Datasheet tab

See Datasheet tab

See Datasheet tab
